Ring die organic fertilizer pellet making machine is a type of granulator. The disc organic fertilizer pellet making machine is lined with high-strength glass fiber reinforced plastic. It has the advantages of uniform granulation, high granulation rate, stable operation, sturdy equipment and long service life.
The disc organic fertilizer pellet making machine is suitable for the processing of bio-organic fertilizer spherical particles, such as coal powder, cement, clinker, fertilizer and other materials. The organic fertilizer pellet machine granulation disc adopts the overall arc structure, and the granulation rate can reach more than 93%.
The granulation tray is provided with three discharge ports, which is convenient for intermittent production operations, greatly reduces labor intensity and improves labor efficiency. The reducer and the motor are driven by flexible belts, which can start smoothly, reduce the impact force and improve the service life of the equipment.
The bottom of the organic fertilizer pellet machine granulation pan is made of multiple radiating steel plates, which are firm and deformed. Thickened, heavier and sturdier base design, no need for anchor bolts, and stable operation.
1. The principle of organic fertilizer pellet making machine:
The working principle of this series of rotary drum organic fertilizer pellet making machines is: the main motor drives the belt and pulley, and the drive shaft is driven by the reducer, and the split gears installed on the drive shaft are in phase with the large gear ring fixed on the body.
The material is added from the feed end and passes through the inside of the cylinder. Under the action of the special structure inside the cylinder, it is made into granules, and then flows out through the discharge port. Due to the continuous entry of materials and the continuous rotation of the organic fertilizer pellet making machine, mass production can be achieved.
2. Features of organic fertilizer pellet machine:
- It adopts a new granulation process integrating multi-functions such as rotation, spheroidization, polishing, densification, heating and drying.
- The spiral slewing mechanism adopts high-strength alloy material, which is durable and prolongs the life of the equipment.
- The material moisture can be granulated between 30% and 40%, and the output moisture is about 30%, which reduces the traditional drying requirements of 70% moisture and effectively reduces the production cost of organic fertilizer.
- During the granulation process, a temperature of 50-65 degrees is generated in the cylinder, which reduces the moisture content of the discharged granules by 5-8 points, thereby reducing the drying cost requirement.
- The granulated pellets by organic fertilizer pellet making machine are uniform, smooth, round and high in strength, and the particle forming rate is over 95%.
- Adjust the size of the discharged material by adjusting the water content of the feed, so as to meet the requirements of different size of the material.
- The fineness of the feed material can be controlled at about 20 mesh, which improves the pulverization process requirement of at least 80 mesh in traditional granulation.
3. Range of organic fertilizer pellet making machine:
Granulation of livestock and poultry manure, composted fertilizers, green manures, sea fertilizers, cake fertilizers, peat, soil and miscellaneous fertilizers, three wastes, microorganisms, municipal solid waste, and organic fermented fertilizers.
This organic fertilizer pellet making machine is suitable for the granulation of light and fine powder materials. The finer the basic particles of the fine powder material, the higher the sphericity of the particles and the better the quality of the ball. Typical application materials: chicken manure, pig manure, cow manure, charcoal, clay, kaolin, etc.
4. Use of organic fertilizer pellet making machine:
Drum organic fertilizer making machine is a kind of granulation equipment commonly used in the production of compound fertilizers, organic fertilizers, biological fertilizers, controlled-release fertilizers and other fertilizers. Production.
5. About organic fertilizer machine manufacturer
Richi Machinery has strong technical force, perfect quality assurance system, and implements a one-stop management model from production to after-sales service. The various organic fertilizer pellet making machine and organic fertilizer pellet production lines produced by RICHI are favored by the majority of users for their high quality, good performance, simple operation and high degree of automation.
Years of production and sales have enabled our company to establish a good cooperative relationship with the vast number of fertilizer factories, various raw material companies, and technical fertilizer companies.
Our company provides one-stop service, from organic fertilizer pellet making machine purchase to raw material purchase and formula consultation to meet the needs of the majority of users, our factory is a professional manufacturer, different from various agencies, so the cost performance is very obvious, our goal is to work with you develop.
Richi Machinery specializes in the production of organic fertilizer granulation equipment, which is used for the molding equipment of organic fertilizers and organic-inorganic compound fertilizers from powder to granular. It is suitable for a wide range of materials, with high spheroidization rate and large output. Liquid trace elements can be added in production. ,improve product quality.
- The organic fertilizer pellet making machine granulating mechanism is novel and reasonable, with reduced weight and height. The process layout is flexible and convenient.
- The inclination of the large plate can be adjusted. The use of angle shims is flexible and convenient to adjust.
- Using a unique combination of unpowered scrapers from organic fertilizer pellet making machine to reduce auxiliary power consumption.
